| Ngõ vào SDI |
1x 10-bit SD/HD switchable |
| Ngõ ra SDI |
1x 10-bit SD/HD switchable |
| Đầu ra kết nối HDMI |
1x HDMI type A |
| Ngõ vào âm thanh SDI |
8 channels embedded in SD and HD |
| Ngõ ra âm thanh SDI |
8 channels embedded in SD and HD |
| Ngõ ra âm thanh HDMI |
2 channels embedded in SD and HD |
| Kết nối máy tính |
USB 3.0 |
| Đồng bộ ngõ vào |
Blackburst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD format |
| Device Control |
Sony-compatible RS-422 deck control port. Serial ports TxRx direction reversible under software control |
| Hỗ trợ định SD |
625/25 PAL, 525/29.97 NTSC, and 525/23.98 NTSC |
| Hỗ trợ định HD |
720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080i59.94, and 1080i60 |
| SDI Compliance |
SMPTE 259M and SMPTE 292M |
| SDI Metadata Support |
VITC read for 3:2 pulldown removal. VANC capture and playback using up to 3 lines of video in file. HD RP188. Closed captioning |
| Video Sampling |
4:2:2 |
| Audio Sampling |
Television standard sample rate of 48 kHz and 24-bit |
| Color Precision |
10-bit |
| Color Space |
REC 601, REC 709 |
| HDMI Color Precision |
10-bit |
| HDMI Resolution |
Pixel-for-pixel HD resolution input to connected device |
| HDMI Configuration |
HDMI automatically configures to connected display |
| Multiple Rate Support |
SDI and HDMI video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s standard definition SDI and 1.5 Gb/s HD-SDI |
| Copy Protection |
For legal reasons HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content |
| Colorspace Conversion |
Hardware-based real time |
| HD Down Conversion |
Software-based down conversion during video playback |
| HD Up Conversion |
Real-time standard definition to 1080HD and 720HD during video capture |
| HD Cross Conversion |
Real time 720 HD to 1080 HD during video capture |
| Real-Time Effects |
Adobe Premiere Pro Mercury Playback Engine effects in DV, MJPEG, DVCPRO HD, DSLR, AVCHD, XDCAM, XDCAM HD, and uncompressed. |
| Software |
Media Express, Disk Speed Test, Blackmagic Control Panel, and Blackmagic driver on Windows |
| Firmware Upgrade |
Firmware built into software driver. Loaded at system start or via updater software |
| Minimum System Requirements |
Compatible with Microsoft Windows 7. Requires a computer with onboard USB 3.0, or a USB 3.0 PCI Express 2.0 card. Does not support USB 2.0 capture and playback |
